RHV SERIES

RHV32

The RHV32 is a vibration head for installing sheet piles and casings. Built for large rigs, large diameters and deep boreholes.

RHV32 drilling head
RHV32

Hollow shaft 92 mm

OVERVIEW
WEIGHT1620 kg
TRACTION160 kN
TORQUEup to 32 kNm
ROTATIONup to 125 min⁻¹
TECHNICAL SPECIFICATIONS

Variable C-Motors · Rotary mechanism RHV32

Performance diagram

Vibrator

FREQUENCY · Hz60
CENTRIFUGAL FORCE · kN160
p = 200 bar · Q = 120 l/min

Drive shafts

Flange connection

Other connections on request

Options

Hydraulic or electric control
Mounting plates
Flushing head
DIMENSIONAL DRAWING
DIMENSIONAL DRAWING RHV32
ALL DIMENSIONS IN MM
IMPRESSIONS FROM THE FIELD
EURODRILL RHV32
RHV32
EURODRILL RHV32
RHV32
